Sphere LED
Display Solutions
Transform any space into a stunning visual experience with seamless spherical LED installations engineered for maximum impact.
Telescopic LED Sphere Engineered for 360° impact
A modular, motorized LED sphere built from independently controlled display segments. Panels expand and retract to create dynamic reveal effects, segmented storytelling, and immersive 360° viewing—ideal for museums, retail flagships, corporate lobbies, exhibitions, and entertainment venues.
True 360° Viewing
Designed to read cleanly from every angle. Whether suspended, pedestal-mounted, or integrated into an architectural feature, the sphere becomes a centerpiece that commands attention in the room.
Independent Module Playback
Each segment can run its own content or lock to a unified canvas—enabling multi-zone narratives, product reveals, and segmented visuals without losing cohesion.
Flexible Installation Methods
Designed to adapt to your space and sightlines. The sphere can be installed as a floor feature, hoisted as a suspended centerpiece, embedded into architectural structures, or integrated into custom frames and scenic builds.
- Floor installation (pedestal or base mount)
- Hoisting / suspension (atriums, lobbies, center-stage)
- Embedded architectural integration
- Custom frames, scenic builds, and exhibit structures
Custom Diameter & Pixel Pitch
Specify the sphere size and resolution to match viewing distance and environment. Options typically range from ultra-fine pitch for close-up interior detail to larger pitch builds for expansive public spaces.
Core Specifications
Specs shown reflect common configurations for this style of system. Final performance is confirmed based on selected pitch, diameter, control chain, and environment.
- Pixel Pitch1.87–4.0 mm
- Refresh Rate1,920–3,840 Hz
- Brightness1,000–1,200 nits
- Gray Scale12–16 bit
- InputAC 100–240V
- Avg. Power150–200 W/m²
- Max. Power450 W/m²
- Lifespan100,000 hrs
- Operating Temp-20°C to 60°C
- Humidity10%–90%
- ApplicationIndoor / Controlled
- Use CasesMuseums • Retail • Events
Installations & Concepts
From compact feature builds to large-scale centerpieces, the system can be configured to suit architecture, sightlines, and creative intent.
Designed & Integrated by Vizidef
Vizidef handles the full build: planning, structure, control architecture, content workflow, commissioning, and long-term support. The result is a sphere system that performs cleanly—day one through years of operation.
- Structural planning & mounting design
- LED processing & system configuration
- Workflow integration (content + playback)
- Calibration, training, and service support
